Industries
Mining
Experts in exploration, production and processing applications.

Choose a category

High abrasion resistant Wear Strips for your critical parts

Bucket loaders protection

Wear Strips (WS) are a composite material made with mild steel and coated with a thick wear resistant alloy specifically designed to sustain high abrasion. Experience shows that compared to hardened plates, WS resist wear several times better. This allows customers not only to reduce cost and maintenance time, but also to decrease the weight of their buckets by using our lighter solution. This finally improves overall production efficiency. WS are today commonly used to protect earth moving machines buckets, shovels and dump truck boxes. They can easily be bent to fit the part profile and welded on the area in contact with the soil.

Providing optimized solutions to increase machines' service life

Castolin Eutectic experience

Based upon hundreds of successful applications approved by our clients across the globe, we provide optimized solutions using a wide range of products and technologies to combat wear. Our field specialists help customers find the best solutions to extend service life of their machines, which ultimately increase efficiency and decrease costs. For instance, our well-known CDP® wearplates are regularly used to protect large surfaces where standard hardened steel plates do not offer sufficient wear resistance.

A cutting process using powerful rotating tools

Drilling

Drilling tools work with abrasive materials of different hardness, texture and dimension, like granite, quartz, basalt, gravel, etc. The main functioning of these engines vary depending if the work is done by percussion fragmentation of the compact ground layers that are less cleavable or by drilling and transporting through rotation of the material that is less compact and relatively cleavable.

These percussion tools (rods) suffer generally of important chocks and abrasion. The choice of the alloys is therefore oriented to cold working deposits resisting to constrains.

Give tools a second life

Shearers

For tools cutting through rotation (auger, drill rod) the type of wear is mainly abrasion combined with weak pressure on the surface. The choice is given rather to alloys presenting a good wear resistance against medium chocks and abrasion under weak pressure.

Alloy protection against chocks and abrasion

Augers

Each tool is specific and the functioning conditions depend on the nature of the ground. Nevertheless, two application possibilities are generally observed:

The wear protection against abrasion with a deposit alloy of the type cast iron to chrome, in cases where the tools suffer of few chocks.

Often, these tools are subject to chocks that damage the protection cords. In this case the deposit of an alloy containing tungsten carbide in a matrix few sensible to chocks is chosen.

Increase efficiency of your machines

Crushing and grinding

The crushing and grinding operations allow a granulometric reduction, more or less strong, of the minerals. Following operations are observed :

  • crushing operation that consists in the reduction of all mine or quarry extracts up to a dimension in the order of centimetre.
  • grinding operation that allows the reduction up to a dimension near the constitutive grain size of the mineral.

It can often be seen that several crushers are mounted in series. The wear of the different components brings a reduction in the machine output. The coating should not only save the piece, it should also increase the lifetime and the efficiency of the machine, i.e. increase the quantity of handled material without the obligation to interrupt the production.

Wear protection for vital crusher parts

Crusher cones

Used for gravel of medium dimension, the wear by abrasion is particularly strong at the cone base (fine particles at the end of the crushing). The coating is made in a circular way, in the sense of the wear or by embossing.

Subject to abrasion

Crusher rotor

The rotor is the main piece of the crusher, it helps to tighten the beaters with help of the fixing corners. The mechanical welded disks are subject to abrasion due to the action of particles on the outer parts of the disk. A preventive coating is recommended on these parts as well as on the flanks.

Avoid equipment failure

Drag chain conveyors

Drag chain conveyors are ideal to carry material such as wood, coal, lime or waste when a change in elevation is required and throughout very long distances. Unfortunately, the abrasive nature of the transported material negatively affects the equipment service life by

  • wearing-out the conveyor surface,
  • increasing the forces required to pull the chain.

Most of the time, high wear appears on the chain path. As a result, the surface is not smooth anymore, forces increase, chain is damaged and parts must regularly be replaced to avoid equipment failure.

4 times more resistant than traditional hardened steel

Wear Sliding Strips (WSS)

Since many years within Castolin Eutectic, we protect our customers’ conveyors surfaces with our well-known CDP® wearplates. Premium polished CDP® were also installed when a low friction surface was required. Today, based on a similar concept, we offer the easy-to-install WSS that protect the chain path against severe abrasion and friction. WSS are a composite material made with mild steel and a specific high wear resistant alloy with low friction coefficient. To ensure good sliding properties and reduce the chain conveyor energy consumption, the strip surface is polished. As a result, our strips are at least least 4 times more resistant than a traditional hardened steel. The surface remains smoother for a longer period of time which eventually also reduces the chain damage. WSS are also suitable for machines that have to sustain high forces and vibrations while working in abrasive environments.
